ACLs
176
Managed Switches
5. Add a static route with IP address 192.268.40.0/24:
a. Select Routing > Routing Table > Basic > Route Configuration.
A screen similar to the following displays.
b. Under Configure Routes, make the following selection and enter the following
information:
• In the Route Type list, select Static.
• In the Network Address field, enter 192.168.40.0.
• In the Subnet Mask field, enter 255.255.255.0.
• In the Next Hop IP Address field, enter 192.168.200.2.
c. Click Add.
6. Create a static route with IP address 192.168.50.0/24:
a. Select Routing > Routing Table > Basic > Route Configuration.
A screen similar to the following displays.
b. Under Configure Routes, make the following selection and enter the following
information:
• In the Route Type list, select Static.
• In the Network Address field, enter 192.168.50.0.
• In the Subnet Mask field, enter 255.255.255.0.
• In the Next Hop IP Address field, enter 192.168.200.2.
c. Click Add.
