2. Create a DiffServ classifier named class_voip and define a single match criterion to
detect UDP packets. The class type match-all indicates that all match criteria defined for
the class must be satisfied in order for a packet to be considered a match.
3. Create a second DiffServ classifier named class_ef and define a single match criterion to
detect a DiffServ code point (DSCP) of EF (expedited forwarding). This handles incoming
traffic that was previously marked as expedited somewhere in the network.
4. Create a DiffServ policy for inbound traffic named pol_voip, then add the previously
created classes class_ef and class_voip as instances within this policy.
This policy handles incoming packets already marked with a DSCP value of EF
(according to the class_ef definition), or marks UDP packets according to the
class_voip definition) with a DSCP value of EF. In each case, the matching packets are
assigned internally to use queue 5 of the egress port to which they are forwarded.
5. Attach the defined policy to an inbound service interface.
(Netgear Switch) (Config)#class-map match-all class_voip
(Netgear Switch) (Config class-map)#match protocol udp
(Netgear Switch) (Config class-map)#exit
(Netgear Switch) (Config)#class-map match-all class_ef
(Netgear Switch) (Config class-map)#match ip dscp ef
(Netgear Switch) (Config class-map)#exit
(Netgear Switch) (Config)#policy-map pol_voip in
(Netgear Switch) (Config policy-map)#class class_ef
(Netgear Switch) (Config policy-class-map)#assign-queue 5
(Netgear Switch) (Config policy-class-map)#exit
(Netgear Switch) (Config policy-map)#class class_voip
(Netgear Switch) (Config policy-class-map)#mark ip-dscp ef
(Netgear Switch) (Config policy-class-map)#assign-queue 5
(Netgear Switch) (Config policy-class-map)#exit
(Netgear Switch) (Config policy-map)#exit
(Netgear Switch) (Config)#interface 1/0/2
(Netgear Switch) (Interface 1/0/2)#service-policy in pol_voip
(Netgear Switch) (Interface 1/0/2)#exit
(Netgear Switch) (Config)#exit
