DiffServ
267
Managed Switches
A screen similar to the following displays.
d. Click Apply.
5. Attach the policy policyicmpv6 to interfaces 1/0/1,1/0/2 and 1/0/3.
a. Select QoS > DiffServ > Advanced > Service Interface Configuration.
A screen similar to the following displays.
b. In the Policy Name list, select policyicmpv6.
c. Select the Interface 1/0/1, 1/0/2, and 1/0/3 check boxes.
