DVMRP
652
Managed Switches
A screen similar to the following displays.
b. Scroll and select the Port 1/0/20 check box.
Now 1/0/20 appears in the Interface field at the top.
c. Enter the following information:
• In the IP Address field, enter 192.168.4.1.
• In the Subnet Mask field, enter 255.255.255.0.
• In the Routing Mode field, select Enable.
d. Click Apply to save the settings.
4. Enable IP multicast on the switch.
a. Select Routing > Multicast > Global Configuration.
A screen similar to the following displays.
b. For Admin Mode, select the Enable radio button.
c. Click Apply.
5. Enable DVMRP on the switch.
a. Select Routing > Multicast > DVMRP> Global Configuration.
To Next Page
