Operation 4-37
To turn on the heaters:
1. Turn on a heater by double clicking the icon in the On/Off column in the Heater Control
Window (Figure 4-31).
A yellow and red icon
indicates the heater is ON.
A gray icon
indicates the heater is OFF.
The heater is operating properly if both of the following are observed:
- The Message column contains any message except “T/C Break”.
- The Present Value (PV) column indicates the heater is heating up to, and stabilizing
at, the set point (SP).
WARNING! The heater will be hot. Avoid touching heater surfaces or burn injury may occur.
2. If the heater is operating properly, click on Exit to close the Heater Control Window. If it is
not operating properly, refer to Section 7 - Troubleshooting or call a trained service
technician.
NOTE The heater file is attached to the program file and is automatically loaded each time the
program file is loaded. This helps to ensure the correct heating profile.
4.10.8.3 Needle Heater
If your system is equipped with a needle heater, select Setup Heater 1 and follow the steps under
4.10.8.2 Heater Tooling to set up the needle heater.
