Adjustments for Better Print Quality (CS2436-7)
● Attaching the Roll Holder to Rolls (6.2.1)
● Loading Rolls in the Printer (6.2.2)
● Loading Sheets in the Printer (6.3.1)
2. On the Tab Selection screen of the Control Panel, press or to select the Settings/
Adj. tab (
).
Note
･ If the Tab Selection screen is not displayed, press the Menu
button.
3. Press the OK button.
The Set./Adj. Menu is displayed.
4. Press or to select Adjust Printer, and then press the OK button.
5. Press or to select Head Posi. Adj., and then press the OK button.
6. Press or to select Manual, and then press the OK button.
A test pattern is printed for adjustment.
7. Press or to select D, and then press the OK button.
8. Press or to select D-1, and then press the OK button.
9. Examine adjustment test pattern D-1 and determine the number with straight lines.
