2. On the Tab Selection screen of the Control Panel, press or to select the Settings/
Adj. tab (
).
Note
ï½¥ If the Tab Selection screen is not displayed, press the Menu
button.
3. Press the OK button.
The Set./Adj. Menu is displayed.
4. Press or to select Adjust Printer, and then press the OK button.
5. Press or to select Feed Priority, and then press the OK button.
6. Press or to select Adj. Quality, and then press the OK button.
7. Press or to select Manual, and then press the OK button.
Test pattern A is printed for manual adjustment.
Note
ï½¥ When printing on sheets, follow the instructions on the Display
Screen and remove the sheet.
8. Examine test pattern A for adjustment. Determine the pattern in which banding is least
noticeable.
Note
ï½¥ If banding seems least noticeable in two patterns but you cannot
decide which one is better, choose an intermediate value.
For example, choose 11 if you cannot decide whether pattern 10 or 12
is better.
