Configuring Dynamic Link Aggregation Quick Steps for Configuring Dynamic Link Aggregation
OmniSwitch AOS Release 7 Network Configuration Guide June 2013 page 8-5
Note. As an option, you can verify your dynamic aggregation group settings with the linkagg range
command on either the actor or the partner switch. For example:
-> show linkagg agg 2
Dynamic Aggregate
SNMP Id : 40000002,
Aggregate Number : 2,
SNMP Descriptor : Dynamic Aggregate Number 2 ref 40000002 size 8,
Name : ,
Admin State : ENABLED,
Operational State : UP,
Aggregate Size : 8,
Number of Selected Ports : 8,
Number of Reserved Ports : 8,
Number of Attached Ports : 8,
Primary Port : 1/1,
LACP
MACAddress : [00:1f:cc:00:00:00],
Actor System Id : [00:20:da:81:d5:b0],
Actor System Priority : 0,
Actor Admin Key : 5,
Actor Oper Key : 0,
Partner System Id : [00:20:da:81:d5:b1],
Partner System Priority : 0,
Partner Admin Key : 5,
Partner Oper Key : 0
When multi-chassis link aggregation feature is activated on the switch, the show linkagg agg command
displays the output as MC-Dynamic aggregate.
You can also use the show linkagg port port command to display information on specific ports. See
“Displaying Dynamic Link Aggregation Configuration and Statistics” on page 8-30 for more
information on show commands.
An example of what these commands look like entered sequentially on the command line on the actor
switch:
-> linkagg lacp agg 2 size 8 actor admin-key 5
-> linkagg lacp port 1/1 actor admin-key 5
-> linkagg lacp port 1/4 actor admin-key 5
-> linkagg lacp port 3/3 actor admin-key 5
-> linkagg lacp port 5/4 actor admin-key 5
-> linkagg lacp port 6/1-2 actor admin-key 5
-> linkagg lacp port 7/3 actor admin-key 5
-> linkagg lacp port 8/1 actor admin-key 5
-> vlan 2 port default 2
