High Availability VLANs Specifications Configuring High Availability VLANs
page 5-2 OmniSwitch AOS Release 7 Network Configuration Guide June 2013
High Availability VLANs Specifications
The table below lists specifications for high availability VLAN software.
High Availability Default Values
The table below lists default values for high availability VLAN software.
Platforms Supported OmniSwitch 10K, 6900
Maximum high availability VLANs per switch 32
Switch ports eligible for high availability VLAN
assignment.
Fixed ports on second-generation Network Interface
(NI) modules.
Switch port not eligible for high availability
VLAN assignment.
Mirroring ports.
CLI Command Prefix Recognition All high availability VLAN configuration commands
with the high availability VLAN prefix support prefix
recognition.
See the “Using the CLI” chapter in the OmniSwitch
AOS Release 7 Switch Management Guide for more
information.
Parameter Description Command Default Value/Comments
Server cluster admin state of the
server cluster
server-cluster admin-state - enable
Server cluster id and mode server-cluster mode - L2
Mac address of the server cluster server-cluster mac-address None
IP address of the server cluster server-cluster ip IP address is configurable only
for L3 clusters.
Configure the port/linkagg of a
server cluster
server-cluster port
server-cluster linkagg
None
