Diagnosing Switch Problems Port Mirroring Overview
OmniSwitch AOS Release 7 Network Configuration Guide June 2013 page 32-3
Port Mirroring Overview
The following sections detail the specifications, defaults, and quick set up steps for the port mirroring
feature. Detailed procedures are found in “Port Mirroring” on page 32-15.
Port Mirroring Specifications
Port Mirroring Defaults
The following table shows port mirroring default values.
Global Port Mirroring Defaults
Platforms Supported OmniSwitch 10K, 6900
Ports Supported Ethernet (10 Mbps)
Fast Ethernet (100 Mbps)
Gigabit Ethernet (1 Gbps)
10 Gigabit Ethernet (10 Gbps)
40 Gigabit Ethernet (40 Gbps)
Mirroring Sessions Supported OmniSwitch 10K - 2 (OS10-XNI-U32 supports 1 session)
OmniSwitch 6900 - 2
Combined Mirroring/Monitoring Ses-
sions per Chassis
OmniSwitch 10K - 3
OmniSwitch 6900 - 2
N-to-1 Mirroring Supported 128 to 1
Number of RPMIR VLANs per session 1
Parameter Description CLI Command Default Value/Comments
Mirroring Session Creation port-mirroring source destination No Mirroring Sessions
Configured
Protection from Spanning Tree
(Spanning Tree Disable)
port-mirroring source destination Spanning Tree Enabled
Mirroring Status Configuration port-mirroring source destination Enabled
Mirroring Session Configuration port-mirroring Enabled
Mirroring Session Deletion port-mirroring No Mirroring Sessions
Configured
