Configuring VLANs Sample VLAN Configuration
OmniSwitch AOS Release 7 Network Configuration Guide June 2013 page 4-3
Sample VLAN Configuration
The following steps provide a quick tutorial to create VLAN 100. Also included are steps to define a
VLAN description, IP router interface, and static switch port assignments.
Note. Optional. Creating a new VLAN involves specifying a VLAN ID that is not already assigned to an
existing VLAN. To determine if a VLAN already exists in the switch configuration, enter show vlan. If
VLAN 100 does not appear in the show vlan output, then it does not exist on the switch. For example:
-> show vlan
vlan type admin oper ip mtu name
-----+------+-----+-----+-----+-----+------------
1 std Ena Dis Dis 1500 VLAN 1
1 Create VLAN 100 with a description (for example, Finance IP Network) using the following
command:
-> vlan 100 name “Finance IP Network”
2 Define an IP interface using the following command to assign an IP host address of 21.0.0.10 to
VLAN 100 that enables forwarding of VLAN traffic to other subnets:
-> ip interface vlan_100_ip address 21.0.0.10 vlan 100
3 Assign switch ports 2 through 4 on slot 3 to VLAN 100 using the following command:
-> vlan 100 members port 3/2-4 untagged
Note. Optional. To verify the VLAN 100 configuration, use the show vlan command. For example:
-> show vlan 100
Name : Finance IP Network,
Type : Static Vlan,
Administrative State : Enabled,
Operational State : Disabled,
IP Router Port : 21.0.0.10 255.0.0.0 forward e2,
IP MTU : 1500
To verify that ports 3/2-4 were assigned to VLAN 100, use the show vlan members command. For
example:
-> show vlan 100 members
port type status
--------+---------+--------------
3/2 default inactive
3/3 default inactive
3/4 default inactive
