Configuring ERP ERP Defaults

OmniSwitch AOS Release 7 Network Configuration Guide June 2013 page 11-3

ERP Defaults

ERP Defaults:

ERPv2 Defaults:

Parameter Description Command Default

ERP ring status erp-ring Disabled

RPL status for the node erp-ring rpl-node Disabled

The wait-to-restore timer value for

the RPL node

erp-ring wait-to-restore 5 minutes

The guard-timer value for the ring

node

erp-ring guard-timer 50 centi-seconds

The NNI-SVLAN association type ethernet-service svlan nni STP

The Ethernet Ring Protection (ERP)

Ring Virtual Channel.

erp-ring virtual-channel Enabled

Revertive mode on a specified node. erp-ring revertive Enabled
