Ethernet Specifications Configuring Ethernet Ports
page 1-2 OmniSwitch AOS Release 7 Network Configuration Guide June 2013
Ethernet Specifications
Ethernet Port Defaults
The following table shows Ethernet port default values:
IEEE Standards Supported 802.3 Carrier Sense Multiple Access with Collision Detection
(CSMA/CD)
802.3u (100BaseTX)
802.3ab (1000BaseT)
802.3z (1000Base-X)
802.3ae (10GBase-X)
802.3ba (40GBase-X)
802.3az (Energy Efficient Ethernet)
Platforms Supported OmniSwitch 10K, 6900
Ports Supported Ethernet (10 Mbps)
Fast Ethernet (100 Mbps)
Gigabit Ethernet (1 Gbps)
10 Gigabit Ethernet (10 Gbps)
40 Gigabit Ethernet (40 Gbps)
Auto Negotiation Supported
Port Mirroring / Monitoring Supported
802.1Q Hardware Tagging Supported
Jumbo Frame Configuration Supported on 1/10/40 Gigabit Ethernet ports
Enhance Port Performance
(EPP)
Supported on OS6900 with 10-Gigabit transceivers
Maximum Frame Size 1553 bytes (10/100 Mbps)
9216 bytes (1/10/40 Gbps)
Parameter Description Command Default Value/Comments
Interface Line Speed interfaces speed AutoNeg
Interface Duplex Mode interfaces duplex AutoNeg
Trap Port Link Messages interfaces link-trap Disabled
Interface Configuration interfaces Enabled
Peak Flood Rate Configuration interfaces flood-limit 4 Mbps (10 Ethernet)
49 Mbps (100 Fast Ethernet)
496 Mbps (1 Gigabit Ethernet)
997 Mbps (10 Gigabit Ethernet)
997 Mbps (40 Gigabit Ethernet)
Interface Alias interfaces alias None configured
Maximum Frame Size interfaces max-frame-
size
1553 (untagged) Ethernet packets
1553 (tagged) Ethernet packets
9216 Gigabit Ethernet packets
