VLAN Stacking Specifications Configuring VLAN Stacking
page 33-2 OmniSwitch AOS Release 7 Network Configuration Guide June 2013
VLAN Stacking Specifications
VLAN Stacking Defaults
Platforms supported OmniSwitch 10K, 6900
IEEE Standards supported IEEE 802.1Q, 2003 Edition, IEEE Standards for Local
and metropolitan area networks—Virtual Bridged
Local Area Networks
P802.1ad/D6.0 (C/LM) Standard for Local and Metro-
politan Area Networks - Virtual Bridged Local Area
Networks - Amendment 4: Provider Bridges
Maximum number of services 4K
Maximum number of SVLANs 4K
Maximum number of SAPs 8K
Maximum number of SAP profiles 8K (1K if profiles assigns priority or bandwidth)
Maximum number of SAP profile VLAN transla-
tion or double tagging rules
8K (4K on OS10K XNI-U32 module)
Maximum number of customer VLANs
(CVLANs) associated with a SAP
4K
Maximum number of service-to-SAP
associations
1K
Parameter Description Command Default Value/Comments
SVLAN administrative and Span-
ning Tree status.
ethernet-service svlan Enabled
Vendor TPID and legacy BPDU sup-
port for STP on a VLAN Stacking
network port.
ethernet-service nni TPID = 0x8100
legacy STP BPDU = dropped.
Acceptable frame types on a VLAN
Stacking user port.
ethernet-service sap cvlan None.
Traffic engineering profile attributes
for a VLAN Stacking Service Access
Point (SAP).
ethernet-service sap-profile ingress bandwidth = shared
ingress bandwidth mbps = 0
CVLAN tag is preserved.
SVLAN priority mapping = 0
