Configuring QoS QoS Specifications
OmniSwitch AOS Release 7 Network Configuration Guide June 2013 page 25-3
QoS Specifications
The QoS functionality described in this chapter is supported on the OmniSwitch 10K and OmniSwitch
6900 switches, unless otherwise stated in the following QoS Specifications table or specifically noted
within any other section of this chapter. Note that any maximum limits provided in the QoS Specifica-
tions table are subject to available system resources.
Maximum number of policy rules 8192
Maximum number of policy conditions 8192
Maximum number of policy actions 8192
Maximum number of policy rules per slot 1024
5120 (OS10K-XNI-U32S, OS10K-GNI-C48E,
OS10K-GNI-U48E).
Maximum number of bandwidth policy rules 2560 (OmniSwitch 10K)
512 (OmniSwitch 6900)
Maximum number of validity periods 64
Maximum number of policy services 256
Maximum number of groups (network, MAC, ser-
vice, port)
2048
Maximum number of group entries 1024 per group (512 per service group)
Maximum number of Class of Service (CoS)
queues per port.
8
Queue Set Profiles (QSP) 4
Weighted Random Early Detection profiles (WRP) 1 (OmniSwitch 6900)
Not supported on the OmniSwitch 10K
Maximum number of QoS policy lists per switch 32 (includes the default list)
Maximum number of QoS policy lists per Universal
Network Profile (UNP)
1
CLI Command Prefix Recognition Some QoS commands support prefix recognition.
See the “Using the CLI” chapter in the OmniSwitch
AOS Release 7 Switch Management Guide for more
information.
