Congestion Management Configuring QoS

page 25-16 OmniSwitch AOS Release 7 Network Configuration Guide June 2013

Strict Priority Profiles (for example, DCP 7)

Weighted Round Robin (WRR)

Profiles

Note: Wn = Weight of UCn

Avg(Wn,Wm) = Average of Weights of UCn & UCm

Queues Priority Precedence

UC7 7 Highest

MC3 7, 6

UC6 6

UC5 5

MC2 5, 4

UC4 4

UC3 3

MC1 3, 2

UC2 2

UC1 1

MC0 1, 0

UC0 0 Lowest

Queues Priority Weight

UC7 7 W7

MC3 7, 6 Avg(W7,W6)

UC6 6 W6

UC5 5 W5

MC2 5, 4 Avg(W5,W4)

UC4 4 W4

UC3 3 W3

MC1 3, 2 Avg(W3,W2)

UC2 2 W2

UC1 1 W1

MC0 1, 0 Avg(W1,W0)

UC0 0 W0
