Omron MX2 User Manual

99
"A" Group: Standard Functions Section 3-5
the inputs to command the inverter output frequency, these parameters adjust
the starting and ending ranges of POT, as well as the output frequency range.
Related characteristic diagrams are located in "Analog Input Settings" in this
chapter.
Analog sampling setting is the value specified in A016.
"A" Function Run
Mode
Edit
Defaults
Func.
Code
Name Description EU Units
A161 [VR] input active range start
frequency
The output frequency correspond-
ing to the analog input range start-
ing point, range is 0.0 to
400.0Hz
*1
8 0.00 Hz
A162 [VR] input active range end fre-
quency
The output frequency correspond-
ing to the current input range end-
ing point, range is 0.0 to
400.0Hz
*2
8 0.00 Hz
A163 [VR] input active range start % The starting point (offset) for the
POT range,
range is 0. to 100.%
8 0. %
A164 [VR] input active range end % The ending point (offset) for the
POT range,
range is 0. to 100.%
8 100. %
A165 [VR] input start frequency
select
Two options; select codes: 00 Use
offset (A161 value) 01 Use 0Hz
8 01 –
*1
Up to 1000Hz for High frequency mode (d060 set to "2")
*2
Up to 1000Hz for High frequency mode (d060 set to "2")

Omron MX2 Specifications

General

Model	MX2
Category	Inverter
Enclosure Rating	IP20
Control Method	V/f control, Sensorless vector control
Frequency Range	0.1 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication	Modbus RTU
Ambient Temperature	-10 to 50 °C (without freezing or condensation)
Overload Capacity	150% for 60 seconds
Cooling Method	Fan Cooled
Humidity	5 to 95% RH (without condensation)
Altitude	Up to 1000m without derating
Voltage	200-240 VAC, 380-480 VAC
Braking Unit	Built-in (for certain models), Optional External
