126
"B" Group: Fine Tuning Functions Section 3-6
When using the brake control function, assign the following signal functions to
intelligent input and output terminals as needed.
1. To input a signal indicating that the brake is released from the external
brake to the inverter, assign the braking confirmation signal (44: BOK) to
one of the terminal 1~7 (C001~C007)
2. Assign the brake release signal (19: BRK), which is a brake-releasing com-
mand, to one of the output terminal 11~12 (C021~C022). To output a signal
when braking is abnormal, assign the brake error signal (20: BER) to an
output terminal.
When using the brake control function, you are recommended to select the
sensorless vector control (A044=03) that ensures a high torque performance
"B" Function Run
Mode
Edit
Defaults
Func.
Code
Name Description EU Units
B120 Brake control enable Two option codes:
00 Disable
01 Enable
8 00
b121 Brake Wait Time for Release Set range: 0.00 to 5.00 sec 8 0.00 Sec
b122 Brake Wait Time for
Acceleration
Set range: 0.00 to 5.00 sec 8 0.00 Sec
b123 Brake Wait Time for Stopping Set range: 0.00 to 5.00 sec 8 0.00 Sec
b124 Brake Wait Time for
Confirmation
Set range: 0.00 to 5.00 sec 8 0.00 Sec
b125 Brake release freq. Set range: 0 to 400 Hz 8 0.00 Hz
b126 Brake release current Set range: 0~200% of inverter
rated current
8 (rated
cur-
rent)
A
b127 Braking freq. setting Set range: 0 to 400 Hz 8 0.00 Hz
