136
"C" Group: Intelligent Terminal Functions Section 3-7
The output logic conversion is programmable for terminal [11], [12] and the
alarm relay terminal. The open-collector output terminal [11] and [12] defaults
to normally open (active low), but you can select normally closed (active high)
for the terminal in order to invert the sense of the logic. You can invert the log-
ical sense of the alarm relay output as well.
You can also adjust the output with ON/OFF delays.
Note If you are using the output terminal OFF delay feature (any of C145, C149 > 0.0
sec.), the [RS] (reset) terminal affects the ON-to-OFF transition slightly. Nor-
mally (with using OFF delays), the [RS] input causes the motor output and the
logic outputs to turn OFF together, immediately. However, when any output
uses an OFF delay, then after the [RS] input turns ON, that output will remain
ON for an additional 1 sec. period (approximate) before turning OFF.
C028 [AM] terminal selection (Ana-
log voltage output 0...10V)
11 programmable functions:
00... Output frequency
01... Output current
02... Output torque
04... Output voltage
05... Input power
06... Electronic thermal load ratio
07... LAD frequency
10... Heat sink temperature
11... Output torque (with code)
13... General output
16... Option
8 07 [LAD-FQ] –
C030 Digital current monitor refer-
ence value
Current with digital current moni-
tor output at 1,440Hz Range is
20%~200% of rated current
9 Rated current A
C047 Pulse train input/output scale
conversion
If EO terminal is configured as
pulse train input (C027=15), scale
conversion is set in C047. Pulse-
out = Pulse-in (C047) Set range
is 0.01 to 99.99
9 1.00 –
"C" Function Run
Mode
Edit
Defaults
Func.
Code
Name Description EU Units
"C" Function Run
Mode
Edit
Defaults
Func.
Code
Name Description EU Units
C031 Output [11] active state Select logic conversion, two
option codes:
00... normally open [NO]
01... normally closed [NC]
8 00 –
C032 Output [12] active state 8 00 –
C036 Alarm relay active state 8 01 –
"C" Function Run
Mode
Edit
Defaults
Func.
Code
Name Description EU Units
C130 Output [11] on delay Set range is 0.0 to 100.0 sec. 8 0.0 Sec.
C131 Output [11] off delay 8 0.0 Sec.
C132 Output [12] on delay Set range is 0.0 to 100.0 sec. 8 0.0 Sec.
C133 Output [12] off delay 8 0.0 Sec.
C140 Relay output on delay Set range is 0.0 to 100.0 sec. 8 0.0 Sec.
C141 Relay output off delay 8 0.0 Sec.
