282
ModBus Data Listing Section B-4
Note 1 Normally, this coil is turned on when the corresponding intelligent input termi-
nal on the control circuit terminal block is turned on or the coil itself is set to
on. In this regard, the operation of the intelligent input terminal has priority
over the operation of the coil. If disconnection of the communication train has
disabled the master system from turning off the coil, turn the corresponding
intelligent input terminal on the control circuit block on and off. This operation
turns off the coil.
Note 2 Communication error data is retained until an error reset command is input.
(The data can be reset during the inverter operation.)
002Dh OL2 (overload notice advance (2)) R 1: ON, 0: OFF
002Eh Odc: Analog O disconnection detec-
tion
– 1: ON, 0: OFF
002Fh OIDc: Analog OI disconnection detec-
tion
– 1: ON, 0: OFF
0030h (Reserved) – –
0031h (Reserved) – –
0032h FBV (PID feedback comparison) R 1: ON, 0: OFF
0033h NDc (communication train disconnec-
tion)
R 1: ON, 0: OFF
0034h LOG1 (logical operation result 1) R 1: ON, 0: OFF
0035h LOG2 (logical operation result 2) R 1: ON, 0: OFF
0036h LOG3 (logical operation result 3) R 1: ON, 0: OFF
0037h (Reserved) – –
0038h (Reserved) – –
0039h (Reserved) – –
003Ah WAC (capacitor life warning) R 1: ON, 0: OFF
003Bh WAF (cooling-fan speed drop) R 1: ON, 0: OFF
003Ch FR (starting contact signal) R 1: ON, 0: OFF
003Dh OHF (heat sink overheat warning) R 1: ON, 0: OFF
003Eh LOC (low-current indication signal) R 1: ON, 0: OFF
003Fh M01 (general output 1) R 1: ON, 0: OFF
0040h M02 (general output 2) R 1: ON, 0: OFF
0041h M03 (general output 3) R 1: ON, 0: OFF
0042h (Reserved) – –
0043h (Reserved) – –
0044h (Reserved) – –
0045h IRDY (inverter ready) R 1: ON, 0: OFF
0046h FWR (forward rotation) R 1: ON, 0: OFF
0047h RVR (reverse rotation) R 1: ON, 0: OFF
0048h MJA (major failure) R 1: ON, 0: OFF
0049h Data writing in progress R 1: Writing in progress, 0: Normal status
004Ah CRC error R 1: Error detected, 0: No error (*2)
004Bh Overrun R 1: Error detected, 0: No error (*2)
004Ch Framing error R 1: Error detected, 0: No error (*2)
004Dh Parity error R 1: Error detected, 0: No error (*2)
004Eh Sum check error R 1: Error detected, 0: No error (*2)
004Fh (Reserved) – –
0050h WCO (window comparator O) R 1: ON, 0: OFF
0051h WCOI (window comparator OI) R 1: ON, 0: OFF
0052h (Reserved) – –
0053h OPDc (option disconnection) R 1: ON, 0: OFF
0054h FREF (FQ command source) R 1: Operator, 0: Others
0055h REF (RUN command source) R 1: Operator, 0: Others
0056h SETM (2nd motor selected) R 1: 2nd motor selected, 0: 1st motor selected
0057h (Reserved) – –
0058h EDM (Gate suppress monitor) R 1: ON, 0: OFF
0059h- unused R inaccessible
Coil No. Item R/W Setting
