284
ModBus Data Listing Section B-4
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
0011h Trip Counter d080 R 0 to 65530 1 [time]
0012h Trip info. 1 (factor) d081 R See the list of inverter trip factors below –
0013h Trip info. 1 (inverter status) See the list of inverter trip factors below –
0014h Trip info. 1 (frequency) (high) 0 to 100000 0.01[Hz]
0015h Trip info. 1 (frequency (low)
0016h Trip info. 1 (current) Output current at tripping 0.01[A]
0017h Trip info. 1 (voltage) DC input voltage at tripping 1[V]
0018h Trip info. 1 (running time) (high) Cumulative running time at tripping 1[h]
0019h Trip info. 1 (running time) (low)
001Ah Trip info. 1 (power-on time) (high) Cumulative power-on time at tripping 1[h]
001Bh Trip info. 1 (power-on time) (low)
001Ch Trip info. 2 (factor) d082 R See the list of inverter trip factors below –
001Dh Trip info. 2 (inverter status) See the list of inverter trip factors below –
001Eh Trip info. 2 (frequency) (high) 0 to 100000 0.01[Hz]
001Fh Trip info. 2 (frequency (low)
0020h Trip info. 2 (current) Output current at tripping 0.01[A]
0021h Trip info. 2 (voltage) DC input voltage at tripping 1[V]
0022h Trip info. 2 (running time) (high) Cumulative running time at tripping 1[h]
0023h Trip info. 2 (running time) (low)
0024h Trip info. 2 (power-on time) (high) Cumulative power-on time at tripping 1[h]
0025h Trip info. 2 (power-on time) (low)
0026h Trip info. 3 (factor) d083 R See the list of inverter trip factors below –
0027h Trip info. 3 (inverter status) See the list of inverter trip factors below –
0028h Trip info. 3 (frequency) (high) 0 to 100000 0.01[Hz]
0029h Trip info. 3 (frequency (low)
002Ah Trip info. 3 (current) Output current at tripping 0.01[A]
002Bh Trip info. 3 (voltage) DC input voltage at tripping 1[V]
002Ch Trip info. 3 (running time) (high) Cumulative running time at tripping 1[h]
002Dh Trip info. 3 (running time) (low)
002Eh Trip info. 3 (power-on time) (high) Cumulative power-on time at tripping 1[h]
002Fh Trip info. 3 (power-on time) (low)
0030h Trip info. 4 (factor) d084 R See the list of inverter trip factors below –
0031h Trip info. 4 (inverter status) See the list of inverter trip factors below –
0032h Trip info. 4 (frequency) (high) 0 to 100000 0.01[Hz]
0033h Trip info. 4 (frequency (low)
0034h Trip info. 4 (current) Output current at tripping 0.01[A]
0035h Trip info. 4 (voltage) DC input voltage at tripping 1[V]
0036h Trip info. 4 (running time) (high) Cumulative running time at tripping 1[h]
0037h Trip info. 4 (running time) (low)
0038h Trip info. 4 (power-on time) (high) Cumulative power-on time at tripping 1[h]
0039h Trip info. 4 (power-on time) (low)
003Ah Trip info. 5 (factor) d085 R See the list of inverter trip factors below –
003Bh Trip info. 5 (inverter status) See the list of inverter trip factors below –
003Ch Trip info. 5 (frequency) (high) 0 to 100000 0.01[Hz]
003Dh Trip info. 5 (frequency (low)
003Eh Trip info. 5 (current) Output current at tripping 0.01[A]
003Fh Trip info. 5 (voltage) DC input voltage at tripping 1[V]
0040h Trip info. 5 (running time) (high) Cumulative running time at tripping 1[h]
0041h Trip info. 5 (running time) (low)
0042h Trip info. 5 (power-on time) (high) Cumulative power-on time at tripping 1[h]
0043h Trip info. 5 (power-on time) (low)
0044h Trip info. 6 (factor) d086 R See the list of inverter trip factors below –
0045h Trip info. 6 (inverter status) See the list of inverter trip factors below –
0046h Trip info. 6 (frequency) (high) 0 to 100000 0.01[Hz]
0047h Trip info. 6 (frequency (low)
0048h Trip info. 6 (current) Output current at tripping 0.01[A]
0049h Trip info. 6 (voltage) DC input voltage at tripping 1[V]
004Ah Trip info. 6 (running time) (high) Cumulative running time at tripping 1[h]
004Bh Trip info. 6 (running time) (low)
004Ch Trip info. 6 (power-on time) (high) Cumulative power-on time at tripping 1[h]
