313
Parameter Settings for Keypad Entry Section C-2
A045 V/f gain 100. ✓
A245 V/f gain, 2nd motor 100. ✓
A046 Voltage compensation gain for
automatic torque boost
100. ✓
A246 Voltage compensation gain for
automatic torque boost, 2nd motor
100. ✓
A047 Slip compensation gain for
automatic torque boost
100. ✓
A247 Slip compensation gain for
automatic torque boost, 2nd motor
100. ✓
A051 DC braking enable 00 ✓
A052 DC braking frequency 0.5 ✓
A053 DC braking wait time 0.0 ✓
A054 DC braking force for deceleration 50 ✓
A055 DC braking time for deceleration 0.5 ✓
A056 DC braking / edge or level detection
for [DB] input
01 ✓
A057 DC braking force at start 0. ✓
A058 DC braking time at start 0.0 ✓
A059 Carrier frequency during DC braking 5.0 ✓
A061 Frequency upper limit 0.0 ✓
A261 Frequency upper limit, 2nd motor 0.0 ✓
A062 Frequency lower limit 0.0 ✓
A262 Frequency lower limit, 2nd motor 0.0 ✓
A063,
A065,
A067
Jump freq. (center) 1 to 3 0.0
0.0
0.0
✓
A064,
A066,
A068
Jump freq. width (hysteresis) 1 to 3 0.5
0.5
0.5
✓
A069 Acceleration hold frequency 0.00 ✓
A070 Acceleration hold time 0.0 ✓
A071 PID enable 00 ✓
A072 PID proportional gain 1.0 ✓
A073 PID integral time constant 1.0 ✓
A074 PID derivative time constant 0.0 ✓
A075 PV scale conversion 1.00 ✓
A076 PV source 00 ✓
A077 Reverse PID action 00 ✓
A078 PID output limit 0.0 ✓
A079 PID feed forward selection 00 ✓
A081 AVR function select 02 ✕
A281 AVR function select, 2nd motor 02 ✕
A082
A282
AVR voltage select
AVR voltage select, 2nd motor
230/400
230/400
✕
✕
A083 AVR filter time constant 0.300 ✓
A084 AVR deceleration gain 100. ✓
A085 Energy-saving operation mode 00 ✕
A086 Energy-saving mode tuning 50.0
✓
A092
A292
Acceleration time (2)
Acceleration time (2), 2nd motor
10.00
10.00
✓
✓
"A" Group Parameters Default Setting B031=10 User
Setting
Func.
Code
Name (EU)
