317
Parameter Settings for Keypad Entry Section C-2
B087 STOP key enable 00 ✓
B088 Restart mode after FRS 00 ✓
B089 Automatic carrier frequency
reduction
01 ✓
B090 Dynamic braking usage ratio 0.0 ✓
B091 Stop mode selection 00 ✓
B092 Cooling fan control 01 ✓
B093 Clear elapsed time of cooling fan 00 ✕
B094 Initialization target data 00 ✕
B095 Dynamic braking control
(BRD) selection
00 ✓
B096 BRD activation level 360/720 ✓
B097 BRD resistor 100.0 ✓
B100 Free-setting V/F freq. (1) 0. ✕
B101 Free-setting V/F volt. (1) 0.0 ✕
B102 Free-setting V/F freq. (2) 0. ✕
B103 Free-setting V/F volt. (2) 0.0 ✕
B104 Free-setting V/F freq. (3) 0. ✕
B105 Free-setting V/F volt. (3) 0.0 ✕
B106 Free-setting V/F freq. (4) 0. ✕
B107 Free-setting V/F volt. (4) 0.0 ✕
B108 Free-setting V/F freq. (5) 0. ✕
B109 Free-setting V/F volt. (5) 0.0 ✕
B110 Free-setting V/F freq. (6) 0. ✕
B111 Free-setting V/F volt. (6) 0.0 ✕
B112 Free-setting V/F freq. (7) 0. ✕
B113 Free-setting V/F volt. (7) 0.0 ✕
B120 Brake control enable 00 ✓
B121 Brake Wait Time for Release 0.00 ✓
B122 Brake Wait Time for Acceleration 0.00 ✓
B123 Brake Wait Time for Stopping 0.00 ✓
B124 Brake Wait Time for Confirmation 0.00 ✓
B125 Brake release freq. 0.00 ✓
B126 Brake release current Rated current ✓
B127 Braking frequency 0.00 ✓
B130 Deceleration overvoltage
suppression enable
00 ✓
B131 Decel. overvolt. suppress level 380 / 760 ✓
B132 Decel. overvolt. suppress const. 1.00 ✓
B133 Decel. overvolt. suppress
proportional gain
0.2 ✓
B134 Decel. overvolt. suppress integral
time
1.0 ✓
B145 GS input mode 00 ✓
B150 Display ex.operator connected 001 ✓
B160 1st parameter of Dual
Monitor
001 ✓
B161 2nd parameter of Dual
Monitor
002 ✓
B163 Freq. set in monitoring 00 ✓
B164 Automatic return to the initial display 00
✓
"B" Group Parameters Default Setting B031=10 User
Setting
Func.
Code
Name (EU)
