40
Step-by-Step Basic Installation Section 2-3
Single-phase 200 V 0.75 to 2.2 kW
Three-phase 200 V 1.5, 2.2 kW
Three-phase 400 V 0.4 to 3.0 kW
Three-phase 200 V 3.7 kW
Three-phase 400 V 4.0 kW
Three-phase 200 V 5.5, 7.5 kW
Three-phase 400 V 5.5, 7.5 kW
Chassis Ground (M4)
L1
Power input Output to Motor
N U/T1 V/T2 W/T3
RB
PD/+1
P/+ N/ -
Single-phase Three-phase
R/L1
Power input Output to Motor
S/L2 T/L3 U/T1 V/T2 W/T3
RB
PD/+1
P/+ N/ -
W/T3 V/T2U/T1 T/L3 S/L2R/L1
N/ -
P/+
PD/+1
RB
Power input Output to Motor
Chassis Ground (M4)
GGRB
N/ -
P/+
PD/+1
W/T3 V/T2U/T1T/L3 S/L2R/L1
Power input Output to Motor
