DESCRIPTION DATA
Assign the trunk route data to the route number
assigned by CM30 Y=00.
•
(1)
(2)
Y=00 Kind of Trunk Route
00-63: Trunk No.
04: Tie line trunk
•
(1)
(2)
Y=01 Dialing signal type
00-63: Trunk Route No.
2: DP 10PPS
•
(1)
(2)
Y=05 Release signal from distant office
00-63: Trunk Route No.
1 : Release signal arrives
•
(1)
(2)
Y=09 Incoming connection signaling
00-63: Trunk Route No.
06: 2nd DT/Timing Start-Tie line
•
(1)
(2)
Y=04 Answer signal from distant office
00-63: Trunk Route No.
2: Answer signal arrives (Tie Line)
•
(1)
(2)
Y=159 8/32-Party Conference trunk
00-63: Trunk Route No.
0: To provide
•
(1)
(2)
Y=14 SMDR for outgoing call
00-63: Trunk Route No.
0: Not provided
NOTE: Be sure to set the PAD for the con-
ference trunk by CM42, for outside
participants.
•
(1)
(2)
Y=19 PAD control of CFTC
00-63: Trunk Route No.
0-3 : Programmable PAD (See CM42)
4-7 : Not used
B
CM35
C
NOVEMBER/15/2006
CONFERENCE (32-PARTY)
