– 231 – NWA-008845-001 Rev.5.0
32ch1004.fm
DESCRIPTION DATA
To use the programmable PAD (CM35 Y=19,
2nd Data=0-3), assign the PAD data by CM42.
(1)
(2)
50-65: See the table below.
00-15: See the table below.
NOTE: When using CFTC-A card, the PAD data is set to 0 dB if the second data is set to 01, 05,
09, and 13.
C
CM42
T/R: Transmitter PAD/Receiver PAD
+: Gain
–: Loss
PATTERNS
1ST DATA
PAD DATA PATTERNS
CONNECTING
PATTERNS
(A TRUNK-B TRUNK)
CM35 Y=19
2ND DATA=0
CM35 Y=19
2ND DATA=1
CM35 Y=19
2ND DATA=2
CM35 Y=19
2ND DATA=3
50
65
50 54 58 62 STA/TONE-CFTC
51 55 59 63 COT/DID/IPT-CFTC
52 56 60 64 ODT (4W E&M)-CFTC
53 57 61 65 DTI/BRT/PRT/CCT/Vir-
tual IPT/CFTC-CFTC
PATTERNS
2ND DATA
PAD DATA OF CFTC (T/R) [dB]
00
15
00 0/0
01 –4 (0)/0
02 –8/0
03 +4/0
04 0/–3
05 –4 (0)/–3
06 –8/–3
07 +4/–3
08 0/–6
09 –4 (0)/–6
10 –8/–6
11 +4/–6
12 0/–9
13 –4 (0)/–9
14 –8/–9
15 +4/–9
~
~
D
NOVEMBER/15/2006
CONFERENCE (32-PARTY)
