DESCRIPTION DATA
Assign the data for Direct Outward Dialing to
the Route number assigned by CM30 Y=00.
NOTE: For Resident System Program, refer
to the Command Manual.
•
(1)
(2)
Y=00 Kind of Route
00-63: Trunk Route No.
00: DDD
01: FX
02: WATS
03: CCSA
•
(1)
(2)
Y=01 Type of Signal
00-63: Trunk Route No.
2: DP
4: DTMF
7: DTMF
•
(1)
(2)
Y=02 OG/IC
00-63: Trunk Route No.
2 : Outgoing
3: Bothway
•
(1)
(2)
Y=04 Answer Signal Condition
00-63: Trunk Route No.
1 : Answer Signal by Polarity Reversal
7 : No Answer Signal
In case of no Answer Signal, system recognizes
the answer in timing set by CM41 Y=0>03.
•
(1)
(2)
Y=05 Release Signal Condition
00-63: Trunk Route No.
0 : No Release Signal from C.O.
1: Release Signal from C.O.
•
(1)
(2)
Y=08 Dial Pulse Sending
00-63: Trunk Route No.
3 : To be sent
•
(1)
(2)
Y=09 Incoming Connection Signalling
00-63: Trunk Route No.
01 : Ring Down (Ground Start)
15 : Ring Down (Loop Start)
A
CM35
B
DIRECT OUTWARD DIALING (DOD)
