NOTE 1: The maximum number of stations that can be provided with the user’s name display is 512. The
maximum number of characters per name is eight, including spaces. The Maintenance Admin-
istration Terminal (MAT) or Customer Administration Terminal (CAT) can be used to register
or change a name. A D
term
can register or change the name assignment of that individual D
term
.
NOTE 2: User names can be assigned to stations that do not have an LCD.
NOTE 3: The trunk name display is provided on a trunk-route basis. The maximum amount of characters
in the trunk name display is four. The maximum number of trunk routes assignable is 16. The
MAT or CAT can be used to register or change a trunk name display.
NOTE 4: There are two ways to change a name that is currently programmed. (1) by overwriting with a
new name, or (2) by inserting a blank space as the first character to cancel the existing name.
DESCRIPTION DATA
Enter the desired station user’s name to each
station number by CM77 Y=0 or CM77 Y=1.
•
(1)
(2)
Y=0 By Character Code
X-XXXXXXXX: Station No.
Character Code 20-7F (Maximum 32 dig-
its)
See APPENDIX B: Character Code Table.
Page B2
•
(1)
(2)
Y=1 By Character
X-XXXXXXXX: Station No.
A-Z, 0-9: Character
(Maximum 16 characters)
Assign the desired trunk name to each trunk
route by CM77 Y=2 or CM77 Y=3.
•
(1)
(2)
Y=2 By Character Code
00-14, 16-63: Trunk Name No. assigned by
CM35 Y=03
Character Code 20-7F (Maximum 8 digits)
See APPENDIX B: Character Code Table.
Page B2
•
(1)
(2)
Y=3 By Character
00-14, 16-63: Trunk Name No. assigned by
CM35 Y=03
A-Z, 0-9: Character
(Maximum 4 characters)
A
CM77
END
JANUARY/20/2006
ALPHANUMERIC DISPLAY
