(2) Data Assignment for Analog Terminal connected to the Analog Port Adapter
DESCRIPTION DATA
Assign an analog terminal station number to
the required LEN.
NOTE: The analog terminal station number
must be assigned to the following
LEN.
Analog Terminal LEN=D
term
LEN
+ 8.
For example, when the DLC card is
mounted on LT01 slot;
For D
term
LEN: 008-015
For Analog Terminal LEN: 016-
023*
*LT02 slot must be vacant.
(1)
(2)
000-763: LEN
FX-FXXXXXXXX: Analog Terminal
Station No.
Assignment Example:
CM10 LEN 000=F 200 for D
term
Primary Extension
CM10 LEN 008=F 300 for Analog Terminal
If level 0 of the LEN is used for the D
term
, the adjacent level 0 must be used.
Assign an analog terminal station number to
the required LEN.
[Series 3200 R6.2 software required]
NOTE: The analog terminal station number
must be assigned to the following
LEN.
Analog Terminal LEN=D
term
LEN
+ 8.
For example, when the DLC card is
mounted on LT01 slot;
For D
term
LEN: 00008-00015
For Analog Terminal LEN:
00016-00023*
*LT02 slot must be vacant.
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
FX-FXXXXXXXX: Analog Terminal
Station No.
Assignment Example:
CM14 LEN 00000=F 200 for D
term
Primary Extension
CM14 LEN 00008=F 300 for Analog Terminal
If level 0 of the LEN is used for the D
term
, the adjacent level 0 must be used.
START
CM10
CM14
A
ANALOG PORT ADAPTER
