– 31 – NWA-008845-001 Rev.5.0
32ch1001.fm
HARDWARE REQUIRED
Analog Port Adapter
DESCRIPTION DATA
Assign a key for analog terminal. •
(1)
(2)
Y=00
Analog Terminal Station No. + + Key
No.
X-XXXXXXXXXX: Analog Terminal
Station No. assigned
by CM10/CM14
Assign an analog terminal station number as
Prime Line.
(1)
(2)
X-XXXXXXXX: Analog Terminal Station
No.
X-XXXXXXXX: Analog Terminal Station
No.
Provide the Analog Port Adapter to the
required stations.
•
(1)
(2)
Y=34
X-XXXXXXXX: Analog Terminal Station
No.
0: To connect
Specify whether a ringing signal is sent to the
analog terminal.
•
(1)
(2)
Y=35
X-XXXXXXXX: My Line No.
0: Not sent
1: To send
Specify the PAD control of the analog
terminal.
•
(1)
(2)
Y=09
X-XXXXXXXX: Analog Terminal Station
No.
0 : Without PAD
1 : With PAD 6dB
A
CM90
,
CM93
CM13
END
JULY/01/2006
ANALOG PORT ADAPTER
To Next Page
