– 466 – NWA-008845-001 Rev.5.0
32ch1008.fm
• For MCI with MP
DESCRIPTION DATA
Assign the number of digits for station number
in MCI message format sent to the VMS from
the MP RS-232C port.
(1)
(2)
708
0 : 6 digits
1 : 8 digits
Assign the function of RS-232C ports.
NOTE: When a port is used for MCI exclu-
sively, assign the 2nd data=10.
When a port is used for both MCI
and Built-in SMDR, assign the 2nd
data=11.
•
(1)
(2)
Y=00
0: Port 0
1: Port 1
10: MCI NOTE
11: MCI and Built-in SMDR NOTE
Assign the attribute data, depending on the
VMS.
•
(1)
(2)
Y=01-06, 08
See the following table.
See the following table.
NOTE: The data should be assigned depending on the attribute of the VMS.
B
CM08
CM40
: Initial Data
Y 1st DATA 2nd DATA
No. MEANING DATA PORT LOCATION No. DATA MEANING
01 Data length 0
1
Port 0
Port 1
0
1
7 bit
8 bit
02 Parity check 0
1
Port 0
Port 1
0
1
Effective
Ineffective
03 Kind of parity 0
1
Port 0
Port 1
0
1
Even parity
Odd parity
04 Stop bit 0
1
Port 0
Port 1
0
1
1-Stop bit
2-Stop bit
05 DTR signal sent to
terminal
0
1
Port 0
Port 1
0
1
Low
High
06 RTS signal sent to
terminal
0
1
Port 0
Port 1
0
1
Low
High
08 Data speed 0
1
Port 0
Port 1
1
2
3
4
5
NONE
1200 bps
2400 bps
4800 bps
9600 bps
19200 bps
9600 bps
C
MESSAGE CENTER INTERFACE (MCI)
PROGRAMMING
To Next Page
