– 472 – NWA-008845-001 Rev.5.0
32ch1008.fm
To add Automatic Number Identification (ANI) information to the MCI message format when the ANI in-
formation is sent from the network, do the following programming.
DESCRIPTION DATA
(1)
(2)
X09: Message Format for Port 0-3
X: 0-3: Port 0-3
0 : Format without ANI
1 : Format with ANI
NOTE: To send the text to the VMS succes-
sively, assign the guard timer.
(1)
(2)
X17: Guard Timer between texts for
Port 0-3
X: 0-3: Port 0-3
0 : No Timer control
1 : 0-128 ms.
2 : 128-256 ms.
3 : 256-384 ms.
4 : 384-512 ms.
5 : 512-640 ms.
DESCRIPTION DATA
Provide sending of ANI information from net-
work to the VMS with MCI.
NOTE: To provide ANI information, be sure
to set CMDD10>X09 2nd data is set
as Format with ANI.
•
(1)
(2)
Y=138
00-63: Trunk Route No.
0: To send
H
CMDD10
I
I
CM35
END
MESSAGE CENTER INTERFACE (MCI)
PROGRAMMING
To Next Page
