Philips Sopho 2000 IPS - Page 489

– 471 – NWA-008845-001 Rev.5.0
32ch1008.fm
DESCRIPTION DATA
(1)
(2)
X03: Data Length for Port 0-3
X: 0-3: Port 0-3
0: 7 bits
1: 8 bits
(1)
(2)
X04: Parity for Port 0-3
X: 0-3: Port 0-3
0 : No Parity
1 : Even Parity
2 : Odd Parity
(1)
(2)
X05: Station Address (SA) for Port 0-3
X: 0-3: Port 0-3
48 : 0
(1)
(2)
X06: Unit Address (UA) for Port 0-3
X: 0-3: Port 0-3
32 : Space (No information)
33 : !
(1)
(2)
X07: Sending the text (Message Waiting
control text sending is available) to
the VMS when the AP00 card is reset
X: 0-3: Port 0-3
0: To send
1: Not sent
(1)
(2)
X08: Number of digits for station number
in the message format to communi-
cate with the VMS
X: 0-3: Port 0-3
0 : 6 digit
1 : 8 digit
G
CMDD10
H
MESSAGE CENTER INTERFACE (MCI)
PROGRAMMING
