– 546 – NWA-008845-001 Rev.5.0
32ch1009.fm
To provide the External TAS Indicator via DK card:
DESCRIPTION DATA
Assign the card number of DK to required
LEN.
NOTE: The DK card number must be as-
signed to the first LEN (Level 0) and
the third LEN (Level 2) of each LT
slot.
(1)
(2)
000-763: LEN
E800-E831 : DK Card No.
For PIM0/1: E800-E807
For PIM2/3: E808-E815
For PIM4/5: E816-E823
For PIM6/7: E824-E831
Assign the card number of DK to required
LEN.
[Series 3200 R6.2 software required]
NOTE: The DK card number must be as-
signed to the first LEN (Level 0) and
the third LEN (Level 2) of each LT
slot.
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
E800-E831 : DK Card No.
For FP No. 00: E800-E807
For FP No. 01: E808-E815
For FP No. 02: E816-E823
For FP No. 03: E824-E831
Specify ON/OFF condition for external relay/
external key on MP built-in DK00 card.
(1)
(2)
700
0 : ON (Ground Start)
OFF (Ground Off [Open])
1 : ON (Ground Off [Open])
OFF (Ground Start)
Assign the TAS Group number assigned by
CM30 Y=17 to circuit number of DK card.
NOTE: MP built-in External Equipment In-
terface is not available for External
TAS Indicator connection.
(1)
(2)
XX Y
XX: 00-31: DK Card No. assigned by
CM10/CM14 (E800-E831)
Y : 0-3: Circuit No.
13XX
XX: 00-63: TAS Group No. 00-63 assigned
by CM30 Y=17
Specify the indication pattern on External TAS
Indicator.
(1)
(2)
00
01 : 30 IPM (1 second ON/OFF)
02 : 60 IPM (0.5 seconds ON/OFF)
03 : 120 IPM (0.25 seconds ON/
OFF)
07 : Steady on
NONE : 120 IPM (0.25 seconds ON/
OFF)
START
CM10
CM14
CM08
CM44
CM59
END
JULY/01/2006
NIGHT SERVICE
TRUNK ANSWER ANY STATION (TAS)
To Next Page
