To provide the telephone set for TAS Indication:
HARDWARE REQUIRED
To provide the External TAS Indicator:
– DK card
– Indicator
Requirement for External Indicator
Control Method: Ground/Battery (-24 V) (Maximum 125 mA)
Type : Visual and/or Audible type with volume control
To provide the telephone set for TAS Indication:
– LC card
– Conventional telephone sets
DESCRIPTION DATA
Assign the TAS Buzzer number (Telephone
set for TAS Indication) to required LEN.
The TAS Buzzer number must correspond to
the TAS Group number assigned by CM30
Y=17.
E600-E663 →TAS Group 00-63
(1)
(2)
000-763: LEN
E600-E663: TAS Buzzer No.
Assign the TAS Buzzer number (Telephone
set for TAS Indication) to required LEN.
The TAS Buzzer number must correspond to
the TAS Group number assigned by CM30
Y=17.
[Series 3200 R6.2 software required]
E600-E663 →TAS Group 00-63
(1)
(2)
XX ZZZ: LEN
XX : 00-59: FP No.
ZZZ: 000-127: Port No.
E600-E663: TAS Buzzer No.
START
CM10
CM14
END
NIGHT SERVICE
TRUNK ANSWER ANY STATION (TAS)
To Next Page
