– 629 – NWA-008845-001 Rev.5.0
32ch1010.fm
DESCRIPTION DATA
Assign the Default Gateway Address for the
system.
•
(1)
(2)
Y=00
02
000000000000-255255255255:
Default Gateway Address for the system
Specify SMDR terminal via LAN port as the
destination to send a Built-in SMDR call infor-
mation.
•
(1)
(2)
Y=01
05: Destination to send a Built-in SMDR
call information
0 : SMDR terminal via LAN port
1 : PMS via LAN port
7 : SMDR terminal via RS port
Specify the Message Format for Built-in
SMDR on IP according to the SMDR terminal
specification.
•
(1)
(2)
Y=01
08: Message Format for Built-in SMDR on
IP
00 : Extended 2400 IMS Format
15 : Former 2400 IMS Format
Assign Service Restriction Class A for SMDR
service for station-to-station calls to the re-
quired stations.
•
(1)
(2)
Y=02
X-XXXXXXXX: Station No.
XX ZZ
XX: 00-15: Service Restriction Class A
Allow SMDR service for station-to-station
calls in Service Restriction Class A assigned
by CM12 Y=02.
[Series 3600 software required]
•
(1)
(2)
Y=213
00-15: Service Restriction Class A as-
signed by CM12 Y=02
0 : Allow
1 : Restricted
Specify whether the parity check is provided
(for SMDR-LAN).
(1)
(2)
827
0 : Not provided (None parity)
1 : To provide (Parity as for CM08>828)
Specify the kind of parity (for SMDR-LAN). (1)
(2)
828
0 : Odd parity
1 : Even parity
A
CM0B
INITIAL
CM04
CM12
CM15
CM08
END
JANUARY/20/2006
STATION MESSAGE DETAIL RECORDING (SMDR)
PROGRAMMING
