– 630 – NWA-008845-001 Rev.5.0
32ch1010.fm
Built-in SMDR Service Programming
To provide an SMDR service, do the following programming in addition to the programming for the Built-
in SMDR on RS-232C or Built-in SMDR on IP.
DESCRIPTION DATA
Assign the Pseudo-Answer signal function
when the answer signal (Battery Reversal) has
not been detected within the time assigned by
CM41 Y=0>03 after making an outgoing trunk
call.
NOTE: This data is effective when CM35
Y=04 is set to “1”.
(1)
(2)
123
0: Not sent
1: To send
Provide the SMDR service for outgoing calls
to the required stations.
•
(1)
(2)
Y=06
X-XXXXXXXX: Station No.
1: To provide
Specify the type of answer signal from distant
office in outgoing connection for each trunk
route.
•
(1)
(2)
Y=04
00-63: Trunk Route No.
1 : Battery Reversal from C.O. line
2 : Answer signal arrives from Tie line/
ISDN
7 : Answer signal does not arrive
Provide the SMDR service for outgoing calls
to the required trunk routes.
•
(1)
(2)
Y=14
00-63: Trunk Route No.
1: To provide
Assign a trunk access code sent to SMDR for
outgoing calls.
•
(1)
(2)
Y=44
00-63: Trunk Route No.
00-99: Trunk access code
Specify the timing of SMDR valid call timer
(pseudo-answer timer).
•
(1)
(2)
Y=0
03: Pseudo-answer timer
00-08: 8-40 seconds
(4 second increments)
If no data is set, the default data is 20-24 sec-
onds.
START
CM08
CM13
CM35
CM41
A
JULY/01/2006
STATION MESSAGE DETAIL RECORDING (SMDR)
PROGRAMMING
To Next Page
