DESCRIPTION DATA
When CM35 Y=01 is 2, assign the data for the
DP Sender Characteristics.
•
(1)
(2)
Y=23 DP Sender Inter Digital Pause
00-63: Trunk Route No.
0 : 300 ms.
1 : 400 ms.
2 : 500 ms.
3 : 600 ms.
4 : 700 ms.
5 : 900 ms.
6: 1100 ms.
7 : 800 ms.
•
(1)
(2)
Y=25 DP Sender Make Ratio
00-63: Trunk Route No.
0 : 39 % Make Ratio
1 : 33 % Make Ratio
•
(1)
(2)
Y=45 DP Sender Release Timing
00-63: Trunk Route No.
0 : 2 seconds
1 : 4 seconds
2 : 6 seconds
3 : 8 seconds
4 : 12 seconds
5 : 14 seconds
6 : 16 seconds
7 : 10 seconds
When CM35 Y=01 is 4, assign data for the
DTMF Sender Characteristics.
•
(1)
(2)
Y=24 DTMF Sender Inter Digital Pause
00-63: Trunk Route No.
0: 32 ms.
1 : 64 ms.
2 : 80 ms.
3 : 96 ms.
4 : 160 ms.
5 : 192 ms.
6 : 240 ms.
7 : 128 ms.
•
(1)
(2)
Y=26 DTMF Sender Signal Width
00-63: Trunk Route No.
0: 64 ms.
1 : 128 ms.
C
CM35
D
TIE LINES
