– 820 – NWA-008845-001 Rev.5.0
32ch2001.fm
HARDWARE REQUIRED
Single Line Telephone with Message Waiting Lamp
8LC or 4LCD/4LCF/4LCL/4LCW card
To provide Front Desk Terminal or PMS:
AP00-B card with AP00 program or AP00-B/AP00-D card with MRCA program
Front Desk Terminal or
PMS
RS RVS-15S CA/RS RVS-4S CA/RS NORM-4S CA (for PMS with AP00 on RS-232C)
DESCRIPTION DATA
Assign the Message Waiting function key to
the D
term
of administrative station or Front
Desk Terminal or Attendant Console, if pro-
vided.
•
(1)
(2)
Y=00
My Line No. + + Key No.
• For administrative station
F0040: Message Waiting Set
F0041: Message Waiting Reset
• For guest station w/o MW Lamp
F1005: Message Waiting Lamp
(1)
(2)
ATTCON No. (E000-E007) + + Key
No.
F6101: Message Waiting
F6104: Reset
Send Message Waiting message to PMS when
setting Message Waiting, if PMS with AP00 on
RS-232C is provided.
(1)
(2)
116
1: To send
Specify whether the printing of Message Wait-
ing set/cancel from Front Desk Terminal is
available or not.
(1)
(2)
154
0 : Available
1 : Not available
Assign the Service Class number for CMD016
to required stations, if PMS with AP00 on RS-
232C is provided.
(1)
(2)
X-XXXX: Station No.
00 -15: Service Class No.
Send Room Status Code which includes Mes-
sage Waiting record, to PMS, if PMS with
AP00 on RS-232C is provided.
(1)
(2)
XX 05: Room Status Code sending to PMS
XX : Service Class No. assigned by
CMD015.
1: To send
B
CM90
,
,
CMD000
CMD015
CMD016
END
JUNE/01/2007
HOTEL SYSTEM PROGRAMMING
MESSAGE WAITING
To Next Page
