Remote Commands
R&S
®
FSW
1047User Manual 1173.9411.02 ─ 43
Suffix:
<n>
.
Window
<t> irrelevant
Parameters:
<Range> Range: 1 dB to 200 dB
*RST: 100 dB
Default unit: HZ
Example:
DISP:TRAC:Y 110dB
Manual operation: See "Range" on page 457
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:AUTO ONCE
Automatic scaling of the y-axis is performed once, then switched off again (for all
traces).
Suffix:
<n>
.
Window
<t> irrelevant
Manual operation: See "Auto Scale Once" on page 458
DISPlay[:WINDow<n>][:SUBWindow<w>]:TRACe<t>:Y[:SCALe]:MODE <Mode>
This command selects the type of scaling of the y-axis (for all traces).
When the display update during remote control is off, this command has no immediate
effect.
Suffix:
<n>
.
Window
<w> subwindow
<t> irrelevant
Parameters:
<Mode> ABSolute
absolute scaling of the y-axis
RELative
relative scaling of the y-axis
*RST: ABSolute
Example:
DISP:TRAC:Y:MODE REL
Manual operation: See "Scaling" on page 458
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:PDIVision <Value>
This remote command determines the grid spacing on the Y-axis for all diagrams,
where possible.
Setting Basic Measurement Parameters
