Remote Commands

R&S

FSW

1050User Manual 1173.9411.02 ─ 43

TRIGger[:SEQuence]:LEVel:VIDeo................................................................................ 1053

TRIGger[:SEQuence]:SLOPe........................................................................................ 1053

TRIGger[:SEQuence]:SOURce......................................................................................1053

TRIGger[:SEQuence]:TIME:RINTerval............................................................................1055

TRIGger[:SEQuence]:DTIMe <DropoutTime>

Defines the time the input signal must stay below the trigger level before a trigger is

detected again.

Parameters:

<DropoutTime> Dropout time of the trigger.

Range: 0 s to 10.0 s

*RST: 0 s

Default unit: S

Manual operation: See "Drop-Out Time" on page 485

TRIGger[:SEQuence]:HOLDoff[:TIME]

Defines the time offset between the trigger event and the start of the sweep.

A negative offset is possible for time domain measurements.

For the trigger sources "External" or "IF Power", a common input signal is used for both

trigger and gate. Therefore, changes to the gate delay will affect the trigger offset as

well.

Parameters:

<Offset> For measurements in the frequency domain, the range is 0 s to

30 s.

For measurements in the time domain, the range is the negative

sweep time to 30 s.

*RST: 0 s

Default unit: S

Example:

TRIG:HOLD 500us

Manual operation: See "Trigger Offset" on page 485

TRIGger[:SEQuence]:IFPower:HOLDoff <Period>

This command defines the holding time before the next trigger event.

Note that this command can be used for any trigger source, not just IF Power

(despite the legacy keyword).

Note: If you perform gated measurements in combination with the IF Power trigger, the

R&S FSW ignores the holding time for frequency sweep, FFT sweep, zero span and

I/Q data measurements.

Setting Basic Measurement Parameters
