Remote Commands
R&S
®
FSW
1174User Manual 1173.9411.02 ─ 43
CALCulate<n>:MARKer<m>:SGRam:Y:MINimum:NEXT
CALCulate<n>:MARKer<m>:SPECtrogram:Y:MINimum:NEXT
This command moves a marker vertically to the next higher minimum level for the cur-
rent frequency.
The search includes all frames. It does not change the horizontal position of the
marker.
Suffix:
<n>
.
Window
<m> Marker
Manual operation: See "Search Mode for Next Peak in Y-Direction" on page 527
CALCulate<n>:MARKer<m>:SGRam:Y:MINimum[:PEAK]
CALCulate<n>:MARKer<m>:SPECtrogram:Y:MINimum[:PEAK]
This command moves a marker vertically to the minimum level for the current fre-
quency.
The search includes all frames. It does not change the horizontal position of the
marker.
If the marker hasn't been active yet, the command first looks for the peak level for all
frequencies and moves the marker vertically to the minimum level.
Suffix:
<n>
.
Window
<m> Marker
Using Delta Markers
The following commands control spectrogram delta markers.
Useful commands for spectrogram markers described elsewhere
The following commands define the horizontal position of the delta markers.
●
CALCulate<n>:DELTamarker<m>:MAXimum:LEFT on page 1166
●
CALCulate<n>:DELTamarker<m>:MAXimum:NEXT on page 1166
●
CALCulate<n>:DELTamarker<m>:MAXimum[:PEAK] on page 1166
●
CALCulate<n>:DELTamarker<m>:MAXimum:RIGHt on page 1166
●
CALCulate<n>:DELTamarker<m>:MINimum:LEFT on page 1167
●
CALCulate<n>:DELTamarker<m>:MINimum:NEXT on page 1167
●
CALCulate<n>:DELTamarker<m>:MINimum[:PEAK] on page 1167
●
CALCulate<n>:DELTamarker<m>:MINimum:RIGHt on page 1168
Remote commands exclusive to spectrogram markers
CALCulate<n>:DELTamarker<m>:SGRam:FRAMe.......................................................... 1175
CALCulate<n>:DELTamarker<m>:SPECtrogram:FRAMe..................................................1175
Analyzing Measurements (Basics)
