R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
1177User Manual 1173.9411.02 ─ 43
<m> Marker
Manual operation: See "Search Mode for Next Peak in Y-Direction" on page 527
CALCulate<n>:DELTamarker<m>:SGRam:Y:MAXimum:BELow
CALCulate<n>:DELTamarker<m>:SPECtrogram:Y:MAXimum:BELow
This command moves a marker vertically to the next higher level for the current fre-
quency.
The search includes only frames below the current marker position. It does not change
the horizontal position of the marker.
Suffix:
<n>
.
Window
<m> Marker
Manual operation: See "Search Mode for Next Peak in Y-Direction" on page 527
CALCulate<n>:DELTamarker<m>:SGRam:Y:MAXimum:NEXT
CALCulate<n>:DELTamarker<m>:SPECtrogram:Y:MAXimum:NEXT
This command moves a delta marker vertically to the next higher level for the current
frequency.
The search includes all frames. It does not change the horizontal position of the
marker.
Suffix:
<n>
.
Window
<m> Marker
Manual operation: See "Search Mode for Next Peak in Y-Direction" on page 527
CALCulate<n>:DELTamarker<m>:SGRam:Y:MAXimum[:PEAK]
CALCulate<n>:DELTamarker<m>:SPECtrogram:Y:MAXimum[:PEAK]
This command moves a delta marker vertically to the highest level for the current fre-
quency.
The search includes all frames. It does not change the horizontal position of the
marker.
If the marker hasn't been active yet, the command looks for the peak level in the whole
spectrogram.
Suffix:
<n>
.
Window
<m> Marker
