R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
1180User Manual 1173.9411.02 ─ 43
Manual operation: See "Defining a Fixed Reference" on page 523
See "Defining Reference Point" on page 539
CALCulate<n>:DELTamarker<m>:FUNCtion:FIXed:RPOint:Y <RefPointLevel>
This command defines the vertical position of the fixed delta marker reference point.
The coordinates of the reference may be anywhere in the diagram.
Suffix:
<n>
.
Window
<m> Marker
Parameters:
<RefPoint> Numeric value that defines the vertical position of the reference.
The unit and value range is variable.
*RST: Fixed Reference: OFF
Default unit: DBM
Example:
CALC:DELT:FUNC:FIX:RPO:Y -10dBm
Sets the reference point level for delta markers to -10 dBm.
Manual operation: See "Defining a Fixed Reference" on page 523
See "Defining Reference Point" on page 539
CALCulate<n>:DELTamarker<m>:FUNCtion:FIXed:RPOint:Y:OFFSet <Offset>
This command defines a level offset for the fixed delta marker reference point.
Suffix:
<n>
.
Window
<m> Marker
Parameters:
<Offset> Numeric value
*RST: 0
Default unit: dB
CALCulate<n>:DELTamarker<m>:FUNCtion:FIXed[:STATe] <State>
This command activates or deactivates a marker that defines a fixed reference point
for relative marker analysis.
If necessary, the command activates a marker and positions it on the peak power.
Subsequently, you can change the coordinates of the fixed reference independent of
the marker. The fixed reference is independent of the trace and is applied to all active
delta markers.
Suffix:
<n>
.
Window
Analyzing Measurements (Basics)
