R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
1215User Manual 1173.9411.02 ─ 43
CALCulate<n>:LIMit<li>:LOWer[:DATA] <LimitLinePoints>
This command defines the vertical definition points of a lower limit line.
Suffix:
<n>
.
irrelevant
<li> Limit line
Parameters:
<LimitLinePoints> Variable number of level values.
Note that the number of vertical values has to be the same as
the number of horizontal values set with CALCulate<n>:
LIMit<li>:CONTrol[:DATA]. If not, the R&S FSW either
adds missing values or ignores surplus values.
The unit depends on CALCulate<n>:LIMit<li>:UNIT
on page 1218.
*RST: Limit line state is OFF
Default unit: DBM
Manual operation: See "Data Points" on page 568
CALCulate<n>:LIMit<li>:LOWer:MARGin <Margin>
This command defines an area around a lower limit line where limit check violations
are still tolerated.
Suffix:
<n>
.
irrelevant
<li> Limit line
Parameters:
<Margin> numeric value
*RST: 0
Default unit: dB
Manual operation: See "Margin" on page 568
CALCulate<n>:LIMit<li>:LOWer:MODE <Mode>
This command selects the vertical limit line scaling.
Suffix:
<n>
.
Window
<li> Limit line
Parameters:
<Mode> ABSolute
Limit line is defined by absolute physical values.
The unit is variable.
Analyzing Measurements (Basics)
