Remote Commands
R&S
®
FSW
1217User Manual 1173.9411.02 ─ 43
Parameters:
<InterpolType> LINear | LOGarithmic
*RST: LIN
Manual operation: See "Y-Axis" on page 568
CALCulate<n>:LIMit<li>:LOWer:STATe <State>
This command turns a lower limit line on and off.
Before you can use the command, you have to select a limit line with CALCulate<n>:
LIMit<li>:NAME on page 1217.
Suffix:
<n>
.
irrelevant
<li> Limit line
Parameters:
<State> ON | OFF | 0 | 1
OFF | 0
Switches the function off
ON | 1
Switches the function on
Manual operation: See "Visibility" on page 565
CALCulate<n>:LIMit<li>:LOWer:THReshold <Threshold>
This command defines a threshold for relative limit lines.
The R&S FSW uses the threshold for the limit check, if the limit line violates the thresh-
old.
Suffix:
<n>
.
irrelevant
<li> Limit line
Parameters:
<Threshold> Numeric value.
The unit depends on CALCulate<n>:LIMit<li>:UNIT
on page 1218.
*RST: -200 dBm
Default unit: DBM
Manual operation: See "Threshold" on page 567
CALCulate<n>:LIMit<li>:NAME <Name>
This command selects a limit line that already exists or defines a name for a new limit
line.
Analyzing Measurements (Basics)
