Remote Commands
R&S
®
FSW
1294User Manual 1173.9411.02 ─ 43
14.10.5.3 CMAP Suffix Assignment
Several commands to change the color settings of individual items of the display or
printout are available. Which item is to be configured is defined using a <CMAP> suffix.
The following assignment applies:
Suffix Description
CMAP1 Background
CMAP2 Grid
CMAP3 *) Common Text
CMAP4 *) Check Status OK
CMAP5 *) Check Status Error
CMAP6 *) Text Special 1
CMAP7 *) Text Special 2
CMAP8 Trace 1
CMAP9 Trace 2
CMAP10 Trace 3
CMAP11 Marker Info Text
CMAP12 Limit Lines
CMAP13 Limit and Margin Check – "Pass"
CMAP14 Limit and Margin Check – "Fail"
CMAP15 *) Softkey Text
CMAP16 *) Softkey Background
CMAP17 *) Selected Field Text
CMAP18 *) Selected Field Background
CMAP19 *) Softkey 3D Bright Part
CMAP20 *) Softkey 3D Dark Part
CMAP21 *) Softkey State "On"
CMAP22 *) Softkey State "Dialog open"
CMAP23 *) Softkey Text Disabled
CMAP24 Logo
CMAP25 Trace 4
CMAP26 Grid – Minorlines
CMAP27 Marker
CMAP28 Display Lines
CMAP29 *) Sweepcount – Text
Configuring the R&S FSW
