Remote Commands
R&S
®
FSW
1293User Manual 1173.9411.02 ─ 43
Parameters:
<hue> tint
Range: 0 to 1
<sat> saturation
Range: 0 to 1
<lum> brightness
Range: 0 to 1
Example:
DISP:CMAP2:HSL 0.3,0.8,1.0
Changes the grid color.
DISPlay:CMAP<it>:PDEFined
<Color>
This command selects a predefined color for various screen elements.
Suffix:
<it>
.
1..n
Selects the item for which the color scheme is to be defined.
For more information see Chapter 14.10.5.3, "CMAP Suffix
Assignment", on page 1294.
Parameters:
<Color> BLACk | BLUE | BROWn | GREen | CYAN | RED | MAGenta |
YELLow | WHITe | DGRay | LGRay | LBLue | LGReen | LCYan |
LRED | LMAGenta
Example:
DISP:CMAP2:PDEF GRE
Manual operation: See "Restoring the User Settings to Default Colors" on page 671
DISPlay:THEMe:CATalog?
This command queries all available display themes.
Return values:
<Themes> String containing all available display themes.
Example:
DISP:THEMe:CAT?
Usage: Query only
DISPlay:THEMe:SELect <Theme>
This command selects the display theme.
Parameters:
<Theme> String containing the name of the theme.
*RST: SPL
Example:
DISP:THEM:SEL "OceanBlue"
Manual operation: See "Theme" on page 668
Configuring the R&S FSW
