R&S FSW Series User Manual

Measurements and Results
R&S
®
FSW
158User Manual 1173.9411.02 ─ 43
Figure 7-22: Repeatability of adjacent channel power measurement on CDMA2000 standard signals if
the integration bandwidth method is used
The Figure 7-23 shows the repeatability of power measurements in the transmit chan-
nel and of relative power measurements in the adjacent channels as a function of
sweep time. The standard deviation of measurement results is calculated from 100
consecutive measurements. Consider the scaling when you compare power values.
Figure 7-23: Repeatability of adjacent channel power measurements on CDMA2000 signals in the fast
ACLR mode
7.2.3.3 Recommended Common Measurement Parameters
The following sections provide recommendations on the most important measurement
parameters for channel power measurements.
Channel Power and Adjacent-Channel Power (ACLR) Measurement
