R&S FSW Series User Manual

Measurements and Results
R&S
®
FSW
276User Manual 1173.9411.02 ─ 43
…
</PowerClass>
●
The "Range" element is structured as follows:
– <Range Index="n">
<Name="Name">
<ChannelType>"Channel Type"</Channel Type>
<WeightingFilter>
<Type>"FilterType"</Type>
<RollOffFactor>"Factor"</RollOffFactor>
<Bandwith>"Bandwidth"</Bandwidth>
</WeightingFilter>
<FrequencyRange>
<Start>"RangeStart"</Start>
<Stop>"RangeStop"</Stop>
</FrequencyRange>
<Limit>
<Start Unit="Unit" Value="Value"/>
<Stop Unit="Unit" Value="Value"/>
</Limit>
<Limit>
<Start Unit="Unit" Value="Value"/>
<Stop Unit="Unit" Value="Value"/>
</Limit>
<RBW Bandwidth="Bandwidth" Type="FilterType"/>
<VBW Bandwidth="Bandwidth"/>
<Detector>"Detector"</Detector>
<Sweep Mode="SweepMode" Time="SweepTime"/>
<Amplitude>
<ReferenceLevel Unit="dBm" Value="Value"/>
<RFAttenuation Mode="Auto" Unit="dB" Value="Value"/>
<Preamplifier State="State"/>
</Amplitude>
<MeasPointsMin>1</MeasPointsMin>
<CalcRuleMulti>Sum</CalcRuleMulti>
</Range>
Table 7-14: Attributes and child nodes of the BaseFormat element
Child Node Attribute Value Parameter Description Mand.
FileFormatVersion 1.0.0.0 Yes
Date YYYY-MM-DD
HH:MM:SS
Date in ISO 8601 format No
Name <string> Name of the standard Yes
Instrument Type FSL Name of the instrument No
Application SA | K72 | K82 Name of the application No
LinkDirection Name Downlink | Uplink |
None
Yes
ShortName DL | UL No
Spectrum Emission Mask (SEM) Measurement
